News

China’s Photoresist: Breaking Through and Advancing
The global semiconductor industry is witnessing significant advancements, particularly in China, where local enterprises are achieving milestones in photoresist production. Hubei Dinglong has secured orders for its advanced ArF and KrF photoresists, while Shenzhen Rongda has received approval for a RMB 244 million private placement to enhance its R&D capabilities. The government’s support further accelerates the industry’s rapid development amid increasing domestic demand for semiconductor materials.

Hubei Dinglong


Launches

China’s Domestic Photoresist Successfully Validated!
Wuhan Taiziwei Optoelectronics has launched the T150 A photoresist, achieving mass production validation. This product, designed to compete with international standards, showcases extreme resolution capabilities and improved process tolerance. This breakthrough signifies a potential shift in China’s reliance on foreign photoresists, as domestic production ramps up in response to growing demand.

Fujifilm Electronic Materials


Charts

Samsung Cuts Photoresist Usage in 3D NAND Production, Boosting Cost Efficiency
Samsung has halved its photoresist usage in 3D NAND production, optimizing manufacturing processes to improve cost efficiency. This change demonstrates significant advancements in semiconductor manufacturing techniques, particularly in enhancing the layering process of NAND flash chips while maintaining high efficiency.

Samsung Logo


Research

EUV Tech Debuts Enhanced FALCON Photoresist Flood Exposure Tool
EUV Tech has introduced the FALCON tool, a next-generation device for characterizing and diagnosing EUV resists. This fully automated system allows for rapid testing and provides critical insights into exposure mechanisms, facilitating advanced photoresist development. Its capabilities include high-throughput analysis and a range of diagnostic modules, enhancing research productivity in the semiconductor field.

FALCON Tool


Insight

Samsung’s Strategic Process Optimization
An interview with Samsung’s production team reveals insights into their recent optimization strategies in 3D NAND manufacturing. By reducing photoresist usage and enhancing coating conditions, Samsung aims to lead in cost efficiency and production capabilities, setting a benchmark for the industry amid rising competition and demand for advanced memory solutions.

Samsung Production


Stay tuned for our next edition where we will continue to bring you the latest and most relevant updates in the semiconductor industry!
